Configuring HTTP/HTTPS for a LoadBalancer Service

1. Log in to the CCE console and click the cluster name to access the cluster console.
2. In the navigation pane, choose Services & Ingresses. In the upper right corner, click Create Service.
3. Configure Service parameters. In this example, only mandatory parameters required for using HTTP/HTTPS are listed. For details about how to configure other parameters, see Using the CCE Console.
   • Service Name: Specify a Service name, which can be the same as the workload name.
   • Service Type: Select LoadBalancer.
   • Selector: Add a label and click Confirm. The Service will use this label to select pods. You can also click Reference Workload Label to use the label of an existing workload. In the dialog box that is displayed, select a workload and click OK.
   • Load Balancer: Select a load balancer type and creation mode.
     • A load balancer can be dedicated or shared. To enable HTTP/HTTPS on the listener port of a dedicated load balancer, the type of the load balancer must be Application (HTTP/HTTPS) or Network (TCP/UDP) & Application (HTTP/HTTPS).
     • This section uses an existing load balancer as an example. For details about the parameters for automatically creating a load balancer, see Table 1.
   • Ports
     • Protocol: Select TCP. If you select UDP, HTTP and HTTPS will be unavailable.
     • Service Port: the port used by the Service. The port number ranges from 1 to 65535.
     • Container Port: the port that the workload listens on. For example, Nginx uses port 80 by default.
     • Frontend Protocol: specifies whether to enable HTTP/HTTPS on the listener port. For a dedicated load balancer, to use HTTP/HTTPS, the type of the load balancer must be Application (HTTP/HTTPS).
   • Listener
     • SSL Authentication: Select this option if HTTPS is enabled on the listener port. This parameter is available only in clusters of v1.23.14-r0, v1.25.9-r0, v1.27.6-r0, v1.28.4-r0, or later versions.
       • One-way authentication: Only the backend server is authenticated. If you also need to authenticate the identity of the client, select two-way authentication.
       • Two-way authentication: Both the clients and the load balancer authenticate each other. This ensures only authenticated clients can access the load balancer. No additional backend server configuration is required if you select this option.
     • CA Certificate: If SSL Authentication is set to Two-way authentication, add a CA certificate to authenticate the client. A CA certificate is issued by a Certificate Authority (CA) and is used to verify the issuer of the client's certificate. If HTTPS mutual authentication is enabled, HTTPS connections can be established only if the client provides a certificate issued by a specific CA.
     • Server Certificate: If HTTPS is enabled on the listener port, you must select a server certificate. If no certificate is available, create one on the ELB console. For details, see Adding a Certificate.
     • SNI: If HTTPS is enabled on the listener port, you must determine whether to add an SNI certificate. Before adding an SNI certificate, ensure the certificate contains a domain name. If no certificate is available, create one on the ELB console. For details, see Adding a Certificate.
     • Security Policy: If HTTPS is enabled on the listener port, you can select a security policy. This parameter is available only in clusters of v1.23.14-r0, v1.25.9-r0, v1.27.6-r0, v1.28.4-r0, or later versions.
     • Backend Protocol: If HTTPS is enabled on the listener port, HTTP or HTTPS can be used to access the backend server. The default value is HTTP. This parameter is available only in clusters of v1.23.14-r0, v1.25.9-r0, v1.27.6-r0, v1.28.4-r0, or later versions.


     If multiple HTTPS Services are released, all listeners will use the same certificate configuration.

   Figure 1 HTTP or HTTPS


4. Click Create.

If a Service uses the HTTP or HTTPS protocol, it is important to take note of the following configuration requirements:

• Different ELB types and cluster versions have different requirements on flavors. For details, see Table 1.
• The two ports in spec.ports must correspond to those in kubernetes.io/elb.protocol-port. In this example, ports 443 and 80 are enabled with HTTPS and HTTP, respectively.

The following uses an automatically created dedicated load balancer as an example.

apiVersion: v1
kind: Service
metadata:
  annotations:
# Specify the Layer 4 and Layer 7 flavors in the parameters for automatically creating a load balancer.
    kubernetes.io/elb.autocreate: '
      {
          "type": "public",
          "bandwidth_name": "cce-bandwidth-1634816602057",
          "bandwidth_chargemode": "bandwidth",
          "bandwidth_size": 5,
          "bandwidth_sharetype": "PER",
          "eip_type": "5_bgp",
          "available_zone": [
              ""
          ],
          "l7_flavor_name": "L7_flavor.elb.s2.small",
          "l4_flavor_name": "L4_flavor.elb.s1.medium"
      }'
    kubernetes.io/elb.class: performance  # A dedicated load balancer
    kubernetes.io/elb.protocol-port: "https:443,http:80"  # HTTP/HTTPS and port number, which must be the same as the port numbers in spec.ports
    kubernetes.io/elb.cert-id: "17e3b4f4bc40471c86741dc3aa211379"  # The certificate ID of the LoadBalancer Service
  labels:
    app: nginx
    name: test
  name: test
  namespace: default
spec:
  ports:
  - name: cce-service-0
    port: 443
    protocol: TCP
    targetPort: 80
  - name: cce-service-1
    port: 80
    protocol: TCP
    targetPort: 80
  selector:
    app: nginx
    version: v1
  sessionAffinity: None
  type: LoadBalancer
