外表创建

本小节所附外表语法用于获取本Tutorial使用到的示例数据。这些示例数据存储在OBS存储桶中,该存储桶向所有经过身份验证的云用户提供了读取权限。

  • 注意,以下语句中的<obs_bucket_name>代表OBS桶名,仅支持部分区域,当前支持的区域和对应的OBS桶名请参见支持区域。GaussDB(DWS) 集群不支持跨区域访问OBS桶数据。
  • 运行时请将示例中的ACCESS_KEY和SECRET_ACCESS_KEY替换用户账户自己的凭证。
  • 创建OBS外表的时候,只做映射关系,不会将数据拉取到GaussDB(DWS)磁盘。
  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
CREATE FOREIGN TABLE obs_from_store_sales_001
(
    ss_sold_date_sk           integer                       ,
    ss_sold_time_sk           integer                       ,
    ss_item_sk                integer               not null,
    ss_customer_sk            integer                       ,
    ss_cdemo_sk               integer                       ,
    ss_hdemo_sk               integer                       ,
    ss_addr_sk                integer                       ,
    ss_store_sk               integer                       ,
    ss_promo_sk               integer                       ,
    ss_ticket_number          bigint                not null,
    ss_quantity               integer                       ,
    ss_wholesale_cost         decimal(7,2)                  ,
    ss_list_price             decimal(7,2)                  ,
    ss_sales_price            decimal(7,2)                  ,
    ss_ext_discount_amt       decimal(7,2)                  ,
    ss_ext_sales_price        decimal(7,2)                  ,
    ss_ext_wholesale_cost     decimal(7,2)                  ,
    ss_ext_list_price         decimal(7,2)                  ,
    ss_ext_tax                decimal(7,2)                  ,
    ss_coupon_amt             decimal(7,2)                  ,
    ss_net_paid               decimal(7,2)                  ,
    ss_net_paid_inc_tax       decimal(7,2)                  ,
    ss_net_profit             decimal(7,2)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/store_sales',
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_store_sales_001;

CREATE FOREIGN TABLE obs_from_date_dim_001
(
    d_date_sk                 integer               not null,
    d_date_id                 char(16)              not null,
    d_date                    date                          ,
    d_month_seq               integer                       ,
    d_week_seq                integer                       ,
    d_quarter_seq             integer                       ,
    d_year                    integer                       ,
    d_dow                     integer                       ,
    d_moy                     integer                       ,
    d_dom                     integer                       ,
    d_qoy                     integer                       ,
    d_fy_year                 integer                       ,
    d_fy_quarter_seq          integer                       ,
    d_fy_week_seq             integer                       ,
    d_day_name                char(9)                       ,
    d_quarter_name            char(6)                       ,
    d_holiday                 char(1)                       ,
    d_weekend                 char(1)                       ,
    d_following_holiday       char(1)                       ,
    d_first_dom               integer                       ,
    d_last_dom                integer                       ,
    d_same_day_ly             integer                       ,
    d_same_day_lq             integer                       ,
    d_current_day             char(1)                       ,
    d_current_week            char(1)                       ,
    d_current_month           char(1)                       ,
    d_current_quarter         char(1)                       ,
    d_current_year            char(1)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/date_dim' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_date_dim_001;

CREATE FOREIGN TABLE obs_from_store_001
(
    s_store_sk                integer               not null,
    s_store_id                char(16)              not null,
    s_rec_start_date          date                          ,
    s_rec_end_date            date                          ,
    s_closed_date_sk          integer                       ,
    s_store_name              varchar(50)                   ,
    s_number_employees        integer                       ,
    s_floor_space             integer                       ,
    s_hours                   char(20)                      ,
    s_manager                 varchar(40)                   ,
    s_market_id               integer                       ,
    s_geography_class         varchar(100)                  ,
    s_market_desc             varchar(100)                  ,
    s_market_manager          varchar(40)                   ,
    s_division_id             integer                       ,
    s_division_name           varchar(50)                   ,
    s_company_id              integer                       ,
    s_company_name            varchar(50)                   ,
    s_street_number           varchar(10)                   ,
    s_street_name             varchar(60)                   ,
    s_street_type             char(15)                      ,
    s_suite_number            char(10)                      ,
    s_city                    varchar(60)                   ,
    s_county                  varchar(30)                   ,
    s_state                   char(2)                       ,
    s_zip                     char(10)                      ,
    s_country                 varchar(20)                   ,
    s_gmt_offset              decimal(5,2)                  ,
    s_tax_precentage          decimal(5,2)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/store' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_store_001;

CREATE FOREIGN TABLE obs_from_item_001
(
    i_item_sk                 integer               not null,
    i_item_id                 char(16)              not null,
    i_rec_start_date          date                          ,
    i_rec_end_date            date                          ,
    i_item_desc               varchar(200)                  ,
    i_current_price           decimal(7,2)                  ,
    i_wholesale_cost          decimal(7,2)                  ,
    i_brand_id                integer                       ,
    i_brand                   char(50)                      ,
    i_class_id                integer                       ,
    i_class                   char(50)                      ,
    i_category_id             integer                       ,
    i_category                char(50)                      ,
    i_manufact_id             integer                       ,
    i_manufact                char(50)                      ,
    i_size                    char(20)                      ,
    i_formulation             char(20)                      ,
    i_color                   char(20)                      ,
    i_units                   char(10)                      ,
    i_container               char(10)                      ,
    i_manager_id              integer                       ,
    i_product_name            char(50)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/item' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_item_001;

CREATE FOREIGN TABLE obs_from_time_dim_001
(
    t_time_sk                 integer               not null,
    t_time_id                 char(16)              not null,
    t_time                    integer                       ,
    t_hour                    integer                       ,
    t_minute                  integer                       ,
    t_second                  integer                       ,
    t_am_pm                   char(2)                       ,
    t_shift                   char(20)                      ,
    t_sub_shift               char(20)                      ,
    t_meal_time               char(20)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/time_dim' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_time_dim_001;

CREATE FOREIGN TABLE obs_from_promotion_001
(
    p_promo_sk                integer               not null,
    p_promo_id                char(16)              not null,
    p_start_date_sk           integer                       ,
    p_end_date_sk             integer                       ,
    p_item_sk                 integer                       ,
    p_cost                    decimal(15,2)                 ,
    p_response_target         integer                       ,
    p_promo_name              char(50)                      ,
    p_channel_dmail           char(1)                       ,
    p_channel_email           char(1)                       ,
    p_channel_catalog         char(1)                       ,
    p_channel_tv              char(1)                       ,
    p_channel_radio           char(1)                       ,
    p_channel_press           char(1)                       ,
    p_channel_event           char(1)                       ,
    p_channel_demo            char(1)                       ,
    p_channel_details         varchar(100)                  ,
    p_purpose                 char(15)                      ,
    p_discount_active         char(1)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/promotion' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_promotion_001;

CREATE FOREIGN TABLE obs_from_customer_demographics_001
(
    cd_demo_sk                integer               not null,
    cd_gender                 char(1)                       ,
    cd_marital_status         char(1)                       ,
    cd_education_status       char(20)                      ,
    cd_purchase_estimate      integer                       ,
    cd_credit_rating          char(10)                      ,
    cd_dep_count              integer                       ,
    cd_dep_employed_count     integer                       ,
    cd_dep_college_count      integer
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/customer_demographics' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_customer_demographics_001;

CREATE FOREIGN TABLE obs_from_customer_address_001
(
ca_address_sk integer not null,
ca_address_id char(16) not null,
ca_street_number char(10) ,
ca_street_name varchar(60) ,
ca_street_type char(15) ,
ca_suite_number char(10) ,
ca_city varchar(60) ,
ca_county varchar(30) ,
ca_state char(2) ,
ca_zip char(10) ,
ca_country varchar(20) ,
ca_gmt_offset float4 ,
ca_location_type char(20)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/customer_address' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_customer_address_001;

CREATE FOREIGN TABLE obs_from_household_demographics_001
(
    hd_demo_sk                integer               not null,
    hd_income_band_sk         integer                       ,
    hd_buy_potential          char(15)                      ,
    hd_dep_count              integer                       ,
    hd_vehicle_count          integer
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/household_demographics' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_household_demographics_001;

CREATE FOREIGN TABLE obs_from_customer_001
(
    c_customer_sk             integer               not null,
    c_customer_id             char(16)              not null,
    c_current_cdemo_sk        integer                       ,
    c_current_hdemo_sk        integer                       ,
    c_current_addr_sk         integer                       ,
    c_first_shipto_date_sk    integer                       ,
    c_first_sales_date_sk     integer                       ,
    c_salutation              char(10)                      ,
    c_first_name              char(20)                      ,
    c_last_name               char(30)                      ,
    c_preferred_cust_flag     char(1)                       ,
    c_birth_day               integer                       ,
    c_birth_month             integer                       ,
    c_birth_year              integer                       ,
    c_birth_country           varchar(20)                   ,
    c_login                   char(13)                      ,
    c_email_address           char(50)                      ,
    c_last_review_date        char(10)
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/customer' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_customer_001;

CREATE FOREIGN TABLE obs_from_income_band_001
(
    ib_income_band_sk         integer               not null,
    ib_lower_bound            integer                       ,
    ib_upper_bound            integer
)
SERVER gsmpp_server
OPTIONS (
LOCATION 'obs://<obs_bucket_name>/tpcds/income_band' ,
FORMAT 'text',
DELIMITER '|',
ENCODING 'utf8',
NOESCAPING 'true',
ACCESS_KEY 'access_key_value_to_be_replaced',
SECRET_ACCESS_KEY 'secret_access_key_value_to_be_replaced',
REJECT_LIMIT 'unlimited',
CHUNKSIZE '64'
)
WITH err_obs_from_income_band_001;
