CREATE RESOURCE POOL

Function

CREATE RESOURCE POOL creates a resource pool and specifies the Cgroup for the resource pool.

Precautions

As long as the current user has CREATE permission, it can create a resource pool.

Syntax

1
2

CREATE RESOURCE POOL pool_name
    [WITH ({MEM_PERCENT=pct | CONTROL_GROUP="group_name" | ACTIVE_STATEMENTS=stmt | MAX_DOP = dop | MEMORY_LIMIT='memory_size' | io_limits=io_limits | io_priority='io_priority' | nodegroup="nodegroupname" | is_foreign=boolean }[, ... ])];

Parameter Description

• pool_name

  Specifies the name of a resource pool.

  The name of a resource pool cannot be same as that of an existing resource pool.

  Value range: a string. It must comply with the naming convention.

• group_name

  Specifies the name of a Cgroup.



  • You can use either double quotation marks ("") or single quotation mark ('') in the syntax when setting the name of a Cgroup.
  • The value of group_name is case-sensitive.
  • If group_name is not specified, the string "Medium" will be used by default in the syntax, indicating the Medium Timeshare Cgroup under DefaultClass.
  • If an administrator specifies a Workload Cgroup under Class, for example, control_group set to class1:workload1, the resource pool will be associated with the workload1 Cgroup under class1. The level of Workload can also be specified. For example, control_group is set to class1:workload1:1.
  • If a database user specifies the Timeshare string (Rush, High, Medium, or Low) in the syntax, for example, if control_group is set to High, the resource pool will be associated with the High Timeshare Cgroup under DefaultClass.
  • In multi-tenant scenarios, the Cgroup associated with a group resource pool is a Class Cgroup, and that associated with a service resource pool is a Workload Cgroup. Additionally, switching Cgroups between different resource pools is not allowed.

  Value range: a string. It must comply with the rule in the description, specifying an existing Cgroup.

• stmt

  Specifies the maximum number of statements that can be concurrently executed in a resource pool.

  Value range: Numeric data ranging from -1 to INT_MAX.

• dop

  This is a reserved parameter.

  Value range: Numeric data ranging from 1 to INT_MAX.

• memory_size

  Specifies the maximum storage for a resource pool.

  Value range: a string, from 1KB to 2047GB.

• mem_percent

  Specifies the proportion of available resource pool memory to the total memory or group user memory.

  In multi-tenant scenarios, mem_percent of group users or service users ranges from 1 to 100. The default value is 20.

  In common scenarios, mem_percent of common users ranges from 0 to 100. The default value is 0.



  When both of mem_percent and memory_limit are specified, only mem_percent takes effect.

• io_limits

  This parameter has been discarded in 8.1.2 and is reserved for compatibility with earlier versions.

• io_priority

  This parameter has been discarded in 8.1.2 and is reserved for compatibility with earlier versions.

• nodegroup

  Specifies the name of a logical cluster where the resource pool is. The logical cluster must already exist.

  If the logical cluster name contains uppercase letters or special characters or begins with a digit, enclose the name with double quotation marks in SQL statements.

• is_foreign

  In logical cluster mode, the current resource pool is used to control the resources of common users who are not associated with the logical cluster specified by nodegroup.



  • nodegroup must specify an existing logical cluster, and cannot be elastic_group or the default Node Group (group_version1), which is generated during cluster installation.
  • If is_foreign is set to true, the resource pool cannot be associated with users. That is, CREATE USER... RESOURCE POOL cannot be used to configure resource pools for users. The resource pool automatically checks whether the users are associated with its logical cluster. If they are not, they will be controlled by the resource pool when performing operations on DNs in the logical cluster.

Examples

This example assumes that Cgroups have been created by users in advance.

Create a default resource pool, and associate it with the Medium Timeshare Cgroup under Workload under DefaultClass.

1

CREATE RESOURCE POOL pool1;

Create a resource pool, and associate it with the High Timeshare Cgroup under Workload under DefaultClass.

1

CREATE RESOURCE POOL pool2 WITH (CONTROL_GROUP="High");

Create a resource pool, and associate it with the Low Timeshare Cgroup under Workload under class1.

1

CREATE RESOURCE POOL pool3 WITH (CONTROL_GROUP="class1:Low");

Create a resource pool, and associate it with the wg1 Workload Cgroup under class1.

1

CREATE RESOURCE POOL pool4 WITH (CONTROL_GROUP="class1:wg1");

Create a resource pool, and associate it with the wg2 Workload Cgroup under class1.

1

CREATE RESOURCE POOL pool5 WITH (CONTROL_GROUP="class1:wg2:3");

Helpful Links

ALTER RESOURCE POOL, DROP RESOURCE POOL
