Elasticsearch向量检索的性能测试和比较

# -*- coding: UTF-8 -*-
import json
import time

import h5py
from elasticsearch import Elasticsearch
from elasticsearch import helpers

def get_client(hosts: list, user: str = None, password: str = None):
    if user and password:
        return Elasticsearch(hosts, http_auth=(user, password), verify_certs=False, ssl_show_warn=False)
    else:
        return Elasticsearch(hosts)

# 索引参数说明请参见在Elasticsearch集群创建向量索引。
def create(es_client, index_name, shards, replicas, dim, algorithm="GRAPH",
           metric="euclidean", neighbors=64, efc=200, shrink=1.0):
    index_mapping = {
        "settings": {
            "index": {
                "vector": True
            },
            "number_of_shards": shards,
            "number_of_replicas": replicas,
        },
        "mappings": {
            "properties": {
                "id": {
                    "type": "integer"
                },
                "vec": {
                    "type": "vector",
                    "indexing": True,
                    "dimension": dim,
                    "algorithm": algorithm,
                    "metric": metric,
                    "neighbors": neighbors,
                    "efc": efc,
                    "shrink": shrink,
                }
            }
        }
    }
    es_client.indices.create(index=index_name, body=index_mapping)
    print(f"Create index success! Index name: {index_name}")

def write(es_client, index_name, vectors, bulk_size=1000):
    print("Start write! Index name: " + index_name)
    start = time.time()
    for i in range(0, len(vectors), bulk_size):
        actions = [{
            "_index": index_name,
            "id": i + j,
            "vec": v.tolist()
        } for j, v in enumerate(vectors[i: i + bulk_size])]
        helpers.bulk(es_client, actions, request_timeout=180)
    print(f"Write success! Docs count: {len(vectors)}, total cost: {time.time() - start:.2f} seconds")
    merge(es_client, index_name)

def merge(es_client, index_name, seg_cnt=1):
    print(f"Start merge! Index name: {index_name}")
    start = time.time()
    es_client.indices.forcemerge(index=index_name, max_num_segments=seg_cnt, request_timeout=7200)
    print(f"Merge success! Total cost: {time.time() - start:.2f} seconds")

# 查询参数说明请参考见在Elasticsearch集群使用向量索引搜索数据。
def query(es_client, index_name, queries, gts, size=10, k=10, ef=200, msn=10000):
    print("Start query! Index name: " + index_name)
    i = 0
    precision = []
    for vec in queries:
        hits = set()
        dsl = {
            "size": size,
            "stored_fields": ["_none_"],
            "docvalue_fields": ["id"],
            "query": {
                "vector": {
                    "vec": {
                        "vector": vec.tolist(),
                        "topk": k,
                        "ef": ef,
                        "max_scan_num": msn
                    }
                }
            }
        }
        res = es_client.search(index=index_name, body=json.dumps(dsl))
        for hit in res['hits']['hits']:
            hits.add(int(hit['fields']['id'][0]))
        precision.append(len(hits.intersection(set(gts[i, :size]))) / size)
        i += 1
    print(f"Query complete! Average precision: {sum(precision) / len(precision)}")

def load_test_data(src):
    hdf5_file = h5py.File(src, "r")
    base_vectors = hdf5_file["train"]
    query_vectors = hdf5_file["test"]
    ground_truths = hdf5_file["neighbors"]
    return base_vectors, query_vectors, ground_truths

def test_sift(es_client):
    index_name = "index_sift_graph"
    vectors, queries, gts = load_test_data(r"sift-128-euclidean.hdf5")
    # 根据实际测试需求调整分片和副本数、索引算法、索引参数等。本文性能测试均配置的是1个分片、2个副本。
    create(es_client, index_name, shards=1, replicas=2, dim=128)
    write(es_client, index_name, vectors)
    query(es_client, index_name, queries, gts)

if __name__ == "__main__":
    # 此处修改为CSS集群的实际访问地址。
    client = get_client(['http://x.x.x.x:9200'])
    test_sift(client)

import base64
import json
import struct

import h5py

def prepare_query(src, dst, size=10, k=10, ef=200, msn=10000, metric="euclidean", rescore=False, use_base64=True):
    """
    使用该函数从hdf5格式的源数据文件读取出query向量，并生成完整的query请求体，用于性能压测。
    :param src: hdf5格式的源数据文件路径。
    :param dst: 目标文件路径。
    :param size: 指定查询返回结果数。
    :param k: 指定Segment级别索引查询topk条相似结果。
    :param ef: 索引查询参数，用于指定查询过程使用的队列大小。
    :param msn: 索引查询参数，用于指定max_scan_num。
    :param metric: 使用何种度量进行rescore精排，euclidean、cosine、inner_product等。
    :param rescore: 是否使用rescore精排，对于GRAPH_PQ索引可以开启精排。
    :param use_base64: 是否使用base64编码的向量数据。
    """
    hdf5_file = h5py.File(src, "r")
    query_vectors = hdf5_file["test"]
    with open(dst, "w", encoding="utf8") as fw:
        for vec in query_vectors:
            query_template = {
                "size": size,
                "stored_fields": ["_none_"],
                "docvalue_fields": ["id"],
                "query": {
                    "vector": {
                        "vec": {
                            "vector": vec.tolist() if not use_base64 else floats2base64(vec),
                            "topk": k,
                            "ef": ef,
                            "max_scan_num": msn,
                        }
                    }
                }
            }
            if rescore:
                query_template["query"]["rescore"] = {
                    "window_size": k,
                    "vector_rescore": {
                        "field": "vec",
                        "vector": vec.tolist() if not use_base64 else floats2base64(vec),
                        "metric": metric
                    }
                }
            fw.write(json.dumps(query_template))
            fw.write("\n")

def floats2base64(vector):
    data = struct.pack('<{}f'.format(len(vector)), *vector)
    return base64.b64encode(data).decode()

if __name__ == "__main__":
    # 修改为数据文件实际地址。
    prepare_query(r"/path/to/sift-128-euclidean.hdf5", r"requests.txt")

local random = math.random

local reqs = {}
local cnt = 0

-- 压测的查询请求文件名称根据需要调整。
for line in io.lines("requests.txt") do
    table.insert(reqs, line)
    cnt = cnt + 1
end


local addrs = {}
local counter = 0
function setup(thread)
   local append = function(host, port)
      for i, addr in ipairs(wrk.lookup(host, port)) do
         if wrk.connect(addr) then
            addrs[#addrs+1] = addr
         end
      end
   end

   if #addrs == 0 then
      -- 根据集群的实际地址进行修改。
      append("x.x.x.x", 9200)
      append("x.x.x.x", 9200)
      append("x.x.x.x", 9200)
   end

   local index = counter % #addrs + 1
   counter = counter + 1
   thread.addr = addrs[index]
end

-- 索引名称根据需要调整。
wrk.path = "/index_sift_graph/_search?request_cache=false&preference=_local"
wrk.method = "GET"
wrk.headers["Content-Type"] = "application/json"


function request()
    return wrk.format(wrk.method, wrk.path, wrk.headers, reqs[random(cnt)])
end
