Setting Alarm Rules

Procedure

1. Log in to the CloudTable console.
2. In the navigation tree, click Cluster Management.
3. In the upper right corner of the cluster list, enter the name of a cluster in the search box and click .
4. In the cluster list, locate the row where the target cluster resides and click View Metric in the Operation column. The CES console is displayed.

   The status of the cluster whose monitoring information you want to view must be In service.

   Figure 1 Viewing the monitoring metrics


5. Click Create Alarm Rule to add an alarm rule.
   1. Enter an alarm rule name and description.
      Figure 2 Configuring an alarm rule name

   2. Configuring the parameters related to the monitoring function.
      Figure 3 Parameters related to the monitoring function


      Table 1 Parameter description

      Parameter	Description	Example Value
      Alarm Type	Default instance or the selected cluster	Metric
      Resource Type	Name of the cloud service resource for which the alarm rule is configured	CloudTable Service
      Dimension	Metric dimension of the alarm rule. Only the Compute Units option is supported.	Computing Units
      Monitoring Scope	Clusters to be monitored	Specific resources
      Monitored Object	Nodes to be monitored	-

   3. Configure alarm policies as prompted.
      Figure 4 Configuring an alarm policy


      Table 2 Parameters for configuring an alarm policy

      Parameter	Description	Example Value
      Method	Select Use existing template or Configure manually as required. If no alarm template is available, set Method to Configure manually and configure related parameters to create an alarm rule. If you have available alarm rule templates, set Method to Use existing template or Associate template, so that you can use a template to quickly create alarm rules.	Create manually
      Template	This parameter is valid only when Use existing template is selected. Select the template to be imported. If no alarm template is available, click Create Custom Template to create one that meets your requirements.	Use Existing Template
      Alarm Policy	This parameter is valid only when Configure manually is selected. For details about the monitoring metrics supported by CloudTable HBase, see HBase Cluster Supported Metrics.	-
      Alarm Severity	Severity of an alarm. Valid values are Critical, Major, Minor, and Informational.	Major

   4. Configure the alarm notification parameters as prompted.
      Figure 5 Alarm notification


      Table 3 Alarm notification parameters

      Parameter	Description	Configuration
      Alarm Notification	Whether to notify users when alarms are triggered. Notifications can be sent by emails, text messages, or HTTP/HTTPS requests. If this function is enabled (recommended), notifications will be sent. Otherwise, no notification is sent.	Toggle it on.
      Notification Recipient	Notification group or topic subscription.	-
      Notification Group/Object	Notification group that needs to send alarm notifications. If you enable Send Notification, you need to select an existing notification group. If you have not created a notification group, click Create Notification Group to access the CES page to create one. Topic to which the alarm notification is to be sent. If you enable Notification, you need to select an existing topic. If you have not created a topic, click Create an SMN Topic to go to the SMN management console to create a topic.	-
      Validity Period	CES sends notifications only within the validity period specified in the alarm rule. If Validity Period is set to 00:00-23:59, CES send notifications only within 00:00-23:59.	The value ranges from 00:00 to 23:59.
      Trigger Condition	Condition for triggering an alarm notification.	Select all options.

   5. Configuring advanced settings.
      Figure 6 Configuring advanced settings


      Table 4 Advanced configuration parameters

      Parameter	Description
      Enterprise Project	You can group related cloud resources (for example, resources used for the same purpose) and manage them by enterprise project.
      Tag	It is recommended that you use TMS's predefined tag function to add the same tag to different cloud resources.

6. After the configuration is complete, click Next. After the alarm rule is created, if the metric data reaches the specified threshold, CES will immediately inform you that an exception has occurred.
   NOTE:

   If you want to set an alarm rule for a single metric, go to the page for viewing monitoring information.

   • View the monitoring metrics and click the metric graph.
   • Click + in the upper right corner.
   • On the page for setting alarm rules, set the rule.
