EXPLAIN PLAN

Description

EXPLAIN PLAN saves information about an execution plan into the PLAN_TABLE table. Different from the EXPLAIN statement, EXPLAIN PLAN only saves plan information and does not print information on the screen.

Precautions

• EXPLAIN PLAN cannot be executed on a DN.
• Plan information cannot be collected for SQL statements that failed to be executed.
• Data in PLAN_TABLE is in a session-level lifecycle. Sessions are isolated from users, and therefore users can only view the data of the current session and current user.
• PLAN_TABLE cannot be joined with GDS foreign tables.
• For a query that cannot be pushed down, only such information as REMOTE_QUERY and CTE can be collected from PLAN_TABLE after EXPLAIN PLAN is executed. For details, see Example 2.
• PLAN: saves plan information into PLAN_TABLE. If information is stored successfully, "EXPLAIN SUCCESS" is returned.
• STATEMENT_ID: tags each query. The tag information will be stored in PLAN_TABLE.
• After the EXPLAIN PLAN statement is executed, plan information is automatically stored in PLAN_TABLE. INSERT, UPDATE, and ANALYZE cannot be performed on PLAN_TABLE. For details about PLAN_TABLE, see PLAN_TABLE.

Syntax

1
2
3

EXPLAIN PLAN
[ SET STATEMENT_ID = name ]
FOR statement ;

Parameters

• name

  Specifies a query tag.

  Value range: a string



  If STATEMENT_ID is not set when the EXPLAIN PLAN statement is executed, STATEMENT_ID is left empty by default. In addition, the value of STATEMENT_ID cannot exceed 30 bytes. Otherwise, an error will be reported.

Example 1

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

-- Create tables foo1 and foo2.
gaussdb=# CREATE TABLE foo1(f1 int, f2 text, f3 text[]);
gaussdb=# CREATE TABLE foo2(f1 int, f2 text, f3 text[]);

-- Run EXPLAIN PLAN.
gaussdb=# EXPLAIN PLAN SET STATEMENT_ID = 'TPCH-Q4' FOR SELECT f1, count(*) FROM foo1 WHERE f1 > 1 AND f1 < 3 AND EXISTS (SELECT * FROM foo2) GROUP BY f1;

-- Query PLAN_TABLE.
gaussdb=# SELECT * FROM plan_table;

-- Delete data from the PLAN_TABLE table and delete tables foo1 and foo2.
gaussdb=# DELETE FROM plan_table WHERE STATEMENT_ID = 'TPCH-Q4';
gaussdb=# DROP TABLE foo1;
gaussdb=# DROP TABLE foo2;

Example 2

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

-- Disable enable_stream_recursive so that associated WITH RECURSIVE queries cannot be pushed down.
gaussdb=# SET enable_stream_recursive = off;

-- Create the chinamap table.
gaussdb=# CREATE TABLE chinamap
(
  id integer,
  pid integer,
  name text
) DISTRIBUTE BY hash(id);

-- Plan collected by plan_table.
gaussdb=# EXPLAIN PLAN SET statement_id = 'cte can not be push down'
FOR
WITH RECURSIVE rq AS
(
  SELECT id, name FROM chinamap WHERE id = 11
  UNION ALL
  SELECT origin.id, rq.name || ' > ' || origin.name
  FROM rq JOIN chinamap origin ON origin.pid = rq.id
)
SELECT id, name FROM rq ORDER BY 1;

-- Query PLAN_TABLE.
gaussdb=# SELECT * FROM plan_table;

-- Delete the chinamap table.
gaussdb=# DROP TABLE chinamap;
