Monitoring a Synchronization Task

Updated on 2024-12-19 GMT+08:00

Scenarios

After a synchronization task is started, you can view the synchronization progress and details at any time.

Procedure

  1. Sign in to the console and go to the OMS page.
  2. In the navigation pane on the left, choose Synchronization Tasks.
  3. Click the task ID and view the task progress. For details about the parameters, see Table 1.

    Figure 1 View the monitoring data of a synchronization task
    Table 1 Monitoring data of a synchronization task

    Parameter

    Description

    Requested Objects (This Month)

    Specifies the number of objects covered by the synchronization requests received from the source platform this month.

    Synced Objects (This Month)

    • Synced

      Specifies the number of objects that have been synchronized this month. You can view the list of synchronized object in the destination bucket.

    • Failed

      Specifies the number of objects that failed to be synchronized this month. You can view the list of failed objects in the destination bucket.

    • Ignored

      Number of objects that have been ignored this month. You can view the list of ignored objects in the destination bucket.

      NOTE:

      If there is an object in the destination bucket with the same name and size as one in the source bucket, but the last modification time of the destination object is later than that of the source object, the source object will be ignored during synchronization.

    Synced Object Size (This Month)

    Specifies the total size of objects that have been synchronized in this month.

    Object Lists

    OMS records objects that are successfully synchronized, failed to be synchronized, and are ignored in three separate lists and stores these lists in the destination bucket. You can use these lists to verify the numbers and names of the synchronized, failed, and ignored objects. For details, see Table 2.

    Synchronization API URL

    Specifies the address for receiving synchronization requests from the source platform. These requests will trigger data synchronizations. For details about the OMS synchronization API, see Creating a Synchronization Event.

    Table 2 Object lists

    Object Type

    Directory

    List Content

    Synced objects

    oms/sync_task/Synchronization task ID/success_object_lists

    Occurrence times (in local UTC), non-URL-encoded names of synchronized objects, and object sizes (in bytes)

    Failed objects

    • oms/sync_task/Synchronization task ID/failed_object_lists
      For example, oms/sync_task/Synchronization task ID/failed_object_lists/oms-task-sync-test-20210107111623197_596
      NOTE:

      This directory stores the list of objects that failed to be synchronized during the migration.

    • oms/sync_task/Synchronization task ID/failed_object_lists/creation_failures
      For example, oms/sync_task/Synchronization task ID/failed_object_lists/creation_failures/1609833838031_5ff41d6e85e877149d44bb55_4.failed_list.txt
      NOTE:

      This directory stores the list of objects that fail to be migrated due to task creation failures. Task creation may fail if the account is in arrears, frozen, or does not have the required permissions.

    Failure cause, occurrence times (in local UTC), URL-encoded and non-URL-encoded names of failed objects, and error codes returned by source SDKs

    Ignored objects

    oms/sync_task/Synchronization task ID/skip_object_lists

    Occurrence times (in local UTC), non-URL-encoded names of ignored objects, and object sizes (in bytes)

    Objects to be synchronized

    oms/sync_task/Synchronization task ID/object_lists

    Names of objects to be synchronized

    NOTE:

    OMS automatically records the names of objects to be synchronized covered by the received synchronization requests in .txt files, and stores the files in the oms/sync_task/Synchronization task ID/object_lists directory of the destination bucket.

    NOTE:

    The statistics displayed on the synchronization task details page are for reference only since they are delayed by about 1 hour.
