Querying Traces in CTS

Scenarios

After you enable CTS and the management tracker is created, CTS starts recording operations on cloud resources. After a data tracker is created, CTS starts recording operations on data in OBS buckets. CTS stores operation records (traces) generated in the last seven days.

This section describes how to query or export operation records of the last seven days on the CTS console.

Video Tutorial

Constraints

• Before the organization function is enabled, you can query the traces of a single account on the CTS console. After the organization function is enabled, you can only view multi-account traces on the Trace List page of each account, or in the OBS bucket or the CTS/system log stream configured for the management tracker with the organization function enabled. For details about organization trackers, see Organization Trackers.
• You can only query operation records of the last seven days on the CTS console. They are automatically deleted upon expiration and cannot be manually deleted. To store them for longer than seven days, configure transfer to Object Storage Service (OBS) or Log Tank Service (LTS) so that you can view them in the OBS buckets or LTS log streams.
• After creating, modifying, or deleting a cloud service resource, you can query management traces on the CTS console one minute later.
• Data traces cannot be viewed on the CTS console. To view data traces, perform the following steps:

  When configuring a data tracker, enable Transfer to LTS. This will automatically transfer data traces recorded by CTS to LTS. You can then view audit logs of data traces in an LTS log stream. For details, see Transferring CTS Traces to LTS and Viewing Them.

Viewing Traces in the Trace List

1. Log in to the CTS console.
2. In the navigation pane, choose Trace List.
3. In the time range drop-down list above the trace list, select a desired query time range: Last 1 hour, Last 1 day, or Last 1 week. You can also specify a custom time range within the last seven days.
4. The search box above the trace list supports advanced queries. Combine one or more filters to refine your search.

   Table 1 Trace filtering parameters

   Parameter	Description
   Read-Only	After selecting the Read-Only filter, you can select either Yes or No from the drop-down list. Yes: filters read-only operation traces, for example, resource query operations. This option is available after Read-Only Trace Reporting has been enabled in the Configuration Center and at least one read-only trace has been triggered. No: filters non-read-only operation traces, such as creating, modifying, and deleting resources.
   Trace Name	Name of a trace. The entered value is case-sensitive and requires an exact match. Fuzzy matching is not supported. For details about the operations that can be audited for each cloud service, see Supported Services and Operations. Example: updateAlarm
   Trace Source	Cloud service name abbreviation. The entered value is case-sensitive and requires an exact match. Fuzzy matching is not supported. Example: IAM
   Resource Name	Name of a cloud resource involved in a trace. The entered value is case-sensitive and requires an exact match. Fuzzy matching is not supported. If the cloud resource involved in the trace does not have a resource name or the corresponding API operation does not involve the resource name parameter, leave this field empty. Example: ecs-name
   Resource ID	ID of a cloud resource involved in a trace. The entered value is case-sensitive and requires an exact match. Fuzzy matching is not supported. Leave this field empty if the resource has no resource ID or if resource creation failed. Example: {VM ID}
   Trace ID	Value of the trace_id parameter for a trace reported to CTS. The entered value requires an exact match. Fuzzy matching is not supported. Example: 01d18a1b-56ee-11f0-ac81-******1e229
   Resource Type	Type of a resource involved in a trace. The entered value is case-sensitive and requires an exact match. Fuzzy matching is not supported. For details about the resource types of each cloud service, see Supported Services and Operations. Example: user
   Operator	User who triggers a trace. Select one or more operators from the drop-down list. If the value of trace_type in a trace is SystemAction, the operation is triggered by the service and the trace's operator may be empty. For details about the relationship between IAM identities and operators and the operator username format, see Relationship Between IAM Identities and Operators.
   Trace Status	Select one of the following options from the drop-down list: normal: The operation succeeded. warning: The operation failed. incident: The operation caused a fault that is more serious than a normal failure, for example, causing other faults.
   Enterprise Project ID	ID of the enterprise project to which a resource belongs. To check enterprise project IDs, go to the Enterprise Project Management Service (EPS) console and choose Project Management in the navigation pane. Example: b305ea24-c930-4922-b4b9-******1eb2
   Access Key	Temporary or permanent access key ID. To check access key IDs, hover over your username in the upper right corner of the console and select My Credentials from the pop-up list. On the displayed page, choose Access Keys in the navigation pane. Example: HSTAB47V9V*******TLN9



5. On the Trace List page, you can also export and refresh the trace list, and customize columns to display.
   • Enter any keyword in the search box and press Enter to filter desired traces.
   • Click Export to export all traces in the query result as an .xlsx file. The file can contain up to 5,000 records.
   • Click to view the latest information about traces.
   • Click to customize the information to be displayed in the trace list. If Auto wrapping is enabled (), excess text will move down to the next line; otherwise, the text will be truncated. By default, this function is disabled.
