Quick Deployment

vpc_name

string

Yes

Virtual Private Cloud (VPC) name. This template uses a newly created VPC. The VPC name must be unique. It can contain 1 to 54 characters. Only letters, digits, underscores (_), hyphens (-), and periods (.) are allowed.

scalable-hpc-cluster-with-slurm-demo

security_group_name

string

Yes

Security group name. This template uses a newly created security group. It can contain 1 to 64 characters. Only letters, digits, underscores (_), hyphens (-), and periods (.) are allowed.

scalable-hpc-cluster-with-slurm-demo

bandwidth_size

number

Yes

Bandwidth size, in Mbit/s. Value range: 1-2,000

5

ecs_name

string

Yes

ECS name. It must be unique. The name is in the {ecs_name}-master or {ecs_name}-node format. It can contain 1 to 57 characters. Only lowercase letters, digits, and hyphens (-) are allowed.

scalable-hpc-cluster-with-slurm-demo

ecs_password

string

Yes

Initial password of an ECS. It can contain 8 to 26 characters, and it must include at least three of the following character types: uppercase letters, lowercase letters, digits, and special characters ($!@%-_=+[]:./^,{}?). The password cannot contain the username or the username spelled backwards. The default administrator account is root.

Left blank

ecs_master_flavor

string

Yes

The flavor of an ECS that can function as a scheduling node. For more flavors, see A Summary List of x86 ECS Specifications.

c6s.xlarge.2

ecs_node_flavor

string

Yes

The flavor of an ECS that can function as a compute node. For more flavors, see A Summary List of x86 ECS Specifications.

c6s.8xlarge.2

keypair_name

string

Yes

The name of the existing SSH key pair. Only account key pairs under Key Pair Service are supported. For details, see Key Pair Management.

Left blank

sfs_turbo_name

string

Yes

The name of an SFS file. It can contain 4 to 64 characters, and it must start with a letter, case-insensitive. Only letters, digits, hyphens (-), and underscores (_) are allowed.

scalable-hpc-cluster-with-slurm-demo

sfs_turbo_size

number

Yes

The size of an SFS file, in GB. SFS file systems provide shared file storage for clusters. Value range: 500-32,768

500

as_name

string

Yes

The name of an auto scaling resource. This template uses a newly created auto scaling group to provide auto scaling for clusters. The name must be unique. It can contain 1 to 50 characters. Only letters, digits, and hyphens (-) are allowed.

scalable-hpc-cluster-with-slurm-demo

charge_mode

string

Yes

Billing mode. It can be prePaid (yearly/monthly) or postPaid (pay-per-use).

postPaid

charge_period_unit

string

Yes

Unit of a subscription term. This parameter is mandatory only when charging_mode is set to prePaid. Value range: month or year

month

charge_period

number

Yes

Subscription term. This parameter is mandatory only when charging_mode is set to prePaid. Value range:

• 1-9 (charging_period_unit set to month)
• 1-3 (charging_period_unit set to year)

1

AK

string

Yes

The Access Key ID (AK) created for configuring Gearbox. For details about how to create and obtain an access key, see 1.

Left blank

SK

string

Yes

The Secret Access Key (SK) created for configuring Gearbox. For details about how to create and obtain an access key, see 1.

Left blank

project_id

string

Yes

The project ID for the region where the solution is deployed. For details about how to obtain the project ID, see Identity and Access Management > Projects.

Left blank
