Operation Guide

Scenario

Figure 1 shows the typical networking where a VPN gateway on Huawei Cloud connects to a VPN gateway on Alibaba Cloud in static routing mode.

Figure 1 Typical networking diagram
Click to enlarge

In this scenario, the Alibaba Cloud VPN gateway has only one IP address, and the Huawei Cloud VPN gateway uses the active-active mode. A VPN connection needs to be created between each of the two active EIPs of the Huawei Cloud VPN gateway and the IP address of the Alibaba Cloud VPN gateway.

Data Plan

**Table 1** Data Plan
Category	Item	Example Value for the Alibaba Cloud Side	Example Value for the Huawei Cloud Side
VPC	Subnet	172.16.0.0/24	192.168.0.0/24
VPN gateway	Gateway IP address	1.1.1.1	Active EIP: 1.1.1.2 Active EIP 2: 2.2.2.2
VPN gateway	Interconnection subnet	-	192.168.2.0/24
VPN connection	Tunnel interface addresses under Connection 1's Configuration	Local tunnel interface address: 169.254.70.1/30 Customer tunnel interface address: 169.254.70.2/30
	Tunnel interface addresses under Connection 2's Configuration	Local tunnel interface address: 169.254.71.1/30 Customer tunnel interface address: 169.254.71.2/30
	IKE policy	IKE version: IKEv2 Authentication algorithm: SHA2-256 Encryption algorithm: AES-128 DH algorithm: Group 14 Local ID: IP address Peer ID: IP address
	IPsec policy	Authentication algorithm: SHA2-256 Encryption algorithm: AES-128 PFS: DH Group 14
