Viewing Traces

Scenarios

After you enable CTS, it records key operations performed on SMS. You can view the operation records of the last seven days on the CTS console.

Procedure

  1. Sign in to the console.
  2. Choose Service List > Management & Governance > Cloud Trace Service.
  3. In the navigation pane on the left, choose Trace List
  4. In the upper right corner of the trace list, click Filter to set the search criteria. The following filters are available:
    • Trace Type, Trace Source, Resource Type, and Search By: Select a filter from the drop-down list.

      When you select Resource ID for Search By, you also need to select or enter a resource ID.

    • Operator: Select a specific operator from the drop-down list.
    • Trace Status: Available options include All trace statuses, Normal, Warning, and Incident.
    • Time range: In the upper right corner of the page, you can query traces in the last one hour, last one day, last one week, or within a customized period.
  5. Click Query.
  6. On the right of the filter box, click Export. CTS exports a CSV file which lists query results.
  7. Click on the left of the required trace to expand its details. Figure 1 shows an example.
    Figure 1 Expanding trace details
  8. Click View Trace in the Operation column. The trace structure details are displayed.
